Automatic paper bag making machine with flat handle
Product advantages
- High productivityFinish the production process of paper bag automatically, fast, efficiently. Various specifications of high-quality paper are enable.
- DurabilityUse world-class manufacturers‘ or joint venture manufacturers’ motors and high precision mechanical components to ensure the durability of the machine. Use World famous brand of high-quality electrical products to ensure the durability of the machine.
- User-friendlyUse VVVF, touch screen, clear full control, finely adjust handle to ensure the operation quick and easy.
Technical parameters
|
S250M-H66 |
M360M-H95 |
L500M-H95 |
| paper bag width |
150-250 mm |
210-380 mm |
260-500 mm |
| bag bottom width |
60-110 mm |
70-150 mm |
70-180 mm |
| sheet width |
490-750 mm |
530-1050 mm |
690-1260 mm |
| sheet length |
270-440 mm |
340-600 mm |
380-620 mm |
| paper tube length |
220-390 mm |
280-540 mm |
320-560 mm |
| card width |
133.4 mm |
188.5 mm |
188.5 mm |
| top folding |
80-90 mm |
80-90 mm |
80-90 mm |
| card length |
66.7 mm |
95 mm |
95 mm |
| punching distance |
150-170 mm |
150-170 mm |
150-170 mm |
| hole diameter |
40-50 mm |
50-60 mm |
50-60 mm |
| power consumption |
14 KW |
15 KW |
17 KW |
| working speed |
45-70 pcs/min |
45-65 pcs/min |
40-60 pcs/min |
Process flow
