Automatic paper bag making machine with insert card
Product advantages
- High productivityFinish the production process of paper bag automatically, fast, efficiently. Various specifications of high-quality paper are enable.
- DurabilityUse world-class manufacturers‘ or joint venture manufacturers’ motors and high precision mechanical components to ensure the durability of the machine. Use World famous brand of high-quality electrical products to ensure the durability of the machine.
- User-friendlyUse VVVF, touch screen, clear full control, finely adjust handle to ensure the operation quick and easy.
Technical parameters
|
S220M-P |
M360M-P |
L500M-P |
| paper bag width |
150-250 mm |
180-360 mm |
260-500 mm |
| bag bottom width |
60-110 mm |
70-150 mm |
70-180 mm |
| sheet width |
490-750 mm |
530-1050 mm |
690-1260 mm |
| sheet length |
270-440 mm |
340-600 mm |
380-620 mm |
| paper tube length |
220-390 mm |
280-540 mm |
320-560 mm |
| card width |
28,30,35 mm |
28,30,35 mm |
28,30,35 mm |
| top folding |
40-50 mm |
50-60 mm |
50-60 mm |
| card length |
130-230 mm |
150-340 mm |
240-480 mm |
| punching distance |
50,75 mm |
80,120 mm |
120,160 mm |
| hole diameter |
3,4,5 mm |
3,4,5 mm |
50-60 mm |
| power consumption |
14 KW |
15 KW |
17 KW |
| working speed |
50-70 pcs/min |
45-65 pcs/min |
40-60 pcs/min |
Process flow
